Mamiya 645 and Phase One Lens Test

I decided to do some testing of my medium format lenses /Phase One Mount/ for my own use. But I think it is much better to share it with broader audience.

Test was done with following conditions:

Camera: Phase One DF

Digital Back: Leaf Aptus 75

Tripod: Manfrotto 055XPROB with Manfrotto 222 head

Self Timer: 3 sec

Distance: 1 meter /only 55-110 was shot at 1.5 meters/

Settings: ISO50, Manual Mode

Speed: 1/50 for f4 lenses, 1/100 for f2.8 lenses and 1/200 for f2.0 lenses

Focus Mode: Autofocus lenses were tested only with autofocus /S mode/. Manual focus lenses were focused with focus confirmation on camera.

Test Target: Distance to from camera was 1.0 meters and target have 3 lines with font sizes:1,2,3

All lenses were tested with 2 shoots, and from following lenses I have 2 copies each:

– Schneider Kreuznach 80mm LS f/2.8 ;  Mamiya 80mm AF f2.8 ; Mamiya 150mm AF f3.5

All copies have given same result.

List of all lenses:

AF-D:  Schneider Kreuznach 80mm AF LS f/2.8, Macro 120/4.0 MF D
AF lenses /not D/ were: 150/3.5 AF (2 copies tested), 80/2.8 AF (2 copies tested), 55/2.8 AF, 45/2.8 AF, 35/3.5 AF, 55-110/4.5 AF
MF: 24/4.0, 30/3.5, 80/1.9, 80/4.0, 110/2.0, 110/2.8, 140/1.8, 150/3.5
Haven’t test yet: 150/2.8 – too big minimum distance and 105-210/4.5AF as it didn’t work with my current body

And here comes the test results.

Here it is how I would rate lenses for center Sharpness and Bokeh:

Premier league:

Mamiya 120mm f4.0 D /Manual Focus/ – Sharpness: 10 Bokeh: 5 (D Version) – MTF for Phase One / Mamiya 120mm Macro Phase One 120mm f/4 D Macro MF Specifications

Mamiya 80mm f4.0  MF  – Sharpness: 10 Bokeh: 5 (C Version)

Schneider Kreuznach 80mm AF LS f/2.8 –  Sharpness: 9 Bokeh: 6 (2 copies tested) – MTF for Schneider Kreuznach 80mm f/2.8 LS Schneider Kreuznach 80mm f2.8 LS Specifications

Mamiya 24mm f4.0 MF Fisheye –  Sharpness: 9 Bokeh: 3 (C Version)

Zeiss 110mm f2.0  /Hasselblad V/  – Sharpness: 8 Bokeh: 9 (F Version)  – MFT for Zeiss 110/2.0 Zeiss 110mm f2.0 Specifications

Mamiya 110mm MF f2.8 – Sharpness: 9 Bokeh: 6 /not shown in photos/

Very Good:

Mamiya 80mm AF f2.8  –  Sharpness: 7 Bokeh: 7  (non D version, 2 copies tested)

Mamiya 80mm MF f1.9 –  Sharpness: 6 Bokeh: 8  (N Version)

Mamiya 55mm AF f2.8 –   Sharpness: 6 Bokeh: 5 (non D version)

Mamiya 45mm AF f2.8 –   Sharpness: 6 Bokeh: 5  (non D version)

Mamiya 150mm MF f3.5 –   Sharpness: 6 Bokeh: 6 (2 copies tested)

Good:

Mamiya 35mm AF f3.5  –  Sharpness: 5 Bokeh: 5  (non D version)

Mamiya 55-110mm AF f4.5  –  Sharpness: 5 Bokeh: 5 (non D version)

Mamiya 150mm AF f3.5 –   Sharpness: 5 Bokeh: 6 (non D version)

Poor:

Russian Lens 35KP 140mm MF f1.8 – Sharpness: 2 Bokeh: 10

Russian Arsat 30mm f3.5 Fisheye  – Sharpness: 1 Bokeh: 1

Haven’t test yet: 150/2.8 MF- too big minimum focus distance and Mamiya105-210/4.5 AF as it didn’t work with my current body

First center sharpness:

Center 100% crop of 200x200px for each lens:

Here are individual photos showing bokeh of Mamiya /  Phase one lenses:

/right click on images and select open in new window to see them in full resolution/

Premier League Lenses:

Mamiya 120mm f4.0 D /Manual Focus/ – Sharpness: 10 Bokeh: 5

One of best mamiya 645 lenses.

Mamiya 80mm f4.0 MF  – Sharpness: 10 Bokeh: 5

Schneider Kreuznach 80mm AF LS f/2.8 –  Sharpness: 9 Bokeh: 6

Mamiya 24mm f4.0 MF Fisheye –  Sharpness: 9 Bokeh: 3

Among the best mamiya 645 lenses.

Zeiss /Hasselblad V/ 110mm f2.0 – Sharpness: 8 Bokeh: 9

Mamiya 110mm MF f2.8 – Sharpness: 9 Bokeh: 7 /not shown in photos/

Very Good:

Mamiya 80mm AF f2.8  –  Sharpness: 7 Bokeh: 7

Mamiya 80mm MF f1.9 –  Sharpness: 6 Bokeh: 8

Mamiya 55mm AF f2.8 –   Sharpness: 6 Bokeh: 5

Mamiya 45mm AF f2.8 –   Sharpness: 6 Bokeh: 5

Mamiya 150mm MF f3.5 –   Sharpness: 6 Bokeh: 6

Good:

Mamiya 35mm AF f3.5  –  Sharpness: 5 Bokeh: 5

Mamiya 55-110mm AF f4.5 (at 1.5m)  –  Sharpness: 5 Bokeh: 5

Mamiya 150mm AF f3.5 –   Sharpness: 5 Bokeh: 6

Poor:

Russian Projector Lens 35KP 140mm MF f1.8 – Sharpness: 2 Bokeh: 10 /cover 48×36 sensor without vignetting!/ –  (shot at 0.7m due to currently use as fixed focus lens, I’m still waiting for focusing helicoid)

Russian Arsat 30mm f3.5 Fisheye  – Sharpness: 1 Bokeh: 1

Arsat turn out to be worst mamiya 645 lens in this lenses review

I hope that you enjoy this Mamiya 645 and Phase One Lens Test Review and it will help you decide which lens you need.

I will add in next days also photos for Mamiya 110mm f2.8 MF, Mamiya 150mm f2.8 MF and Mamiya 105-210mm f4.5 AF as they were not included in this test.
